| Code | Items | Parameters |
|---|---|---|
| 1 | Robot Cell (FANUC) | M20iD/35 |
| 2 | Sand Belt Machine | 1421*1625*2385mm |
| 3 | Cloth wheel polishing machine | 1000*1500*2200mm |
| 4 | Double-layers feeding table | Double-layers feeding table |
| 5 | Fixture | 400 mm |
| 6 | Max. Power of sand belt machine | 16 KW |
| 7 | Max. Power of cloth wheel polishing machine | 17.5 KW |
| 8 | Machine base | Standard Base Provided |
| 9 | Voltage | 380V |
| 10 | Sand Belt specification | 4000MM / 2500MM |
| 11 | Max. Liner speed of grinding | 29M/S |
| 12 | Max. Liner speed of polishing | 45M/S |
| 13 | Three-phase induction motor | 3KW-4P (1440r/min) |
| 14 | Air Pressure | 0.4 ~ 0.7Mpa |
| 15 | Machine size | 2400*3800*2700mm |
| 16 | Total Weight | 4000KG |
| 17 | Air cylinder | AirTAC |
| 18 | Bearing | NSK |
| 19 | Open guide slide block | LSPB |
| 20 | Open linear guide | LSPB |
| 21 | Three-phase induction motor brand | Planet |
| 22 | HMI | Delta |
| 23 | PLC | Delta |
| 24 | Cloth wheels dimension | Dia. 600 (Width customizable) |
| Code | Items | Details | Remarks |
|---|---|---|---|
| 1 | Machine warranty | 12 months | Complete system coverage |
| 2 | Service response time | Within 24 hours | Remote tech-support window |
| 3 | Installation and Commissioning Fees |
- Within 10 days included - Over 10 days: USD 200 per day / per person (plus travel and lodging) - Translator, additional travel costs, meals, and accommodation covered by end user |
On-site support services |
1. Package includes: 1 set of random attached fixture, buffs, and polishing wax.
2. Payment terms: 50% TT deposit upon contract execution; remaining 50% TT balance settled prior to delivery dispatch.
3. Lead time: Standard shipment scheduled 90 days following formal contract validation.
