✦ The tertiary induction ring is placed vertically and connected in the middle, which promotes the metal wave to circulate through the groove, which is beneficial to degassing, impurity removal and uniform chemical composition. If either of the two induction loops stops working, it can be heated by the other induction loop to re-melt and resume operation.
✦ The coil is cooled by an exhaust system.
✦ According to the required copper output per hour, the electric furnace automatically selects the most suitable one of the 6 power string gears for heating or heat preservation under PID control mode; so that the temperature of copper water can be accurately controlled and electric energy can be saved.
| Code | Name | Unit | Data (125kw) |
|---|---|---|---|
| 1 | Capacity | KG | 1050 |
| 2 | Power | KW | 125 |
| 3 | Supply voltage and frequency | V | 400V/50Hz |
| 4 | Apparent power (6 gears) | KVA | 180 |
| 5 | Compensation power | KVA | 120 |
| 6 | Copper melting rate | T/Hr | 0.3 |
| 7 | Exhaust capacity | m³/h | 4000 |
| 8 | Working Temperature | °C | 1050 |
| 9 | Power Factor | - | 0.95 (before compensation) 0.9~1 (after compensation) |
| 10 | Exhaust pressure | Pa | 400 |
| 11 | Exhaust motor speed | r/m | 1450r/m |
| 12 | Exhaust motor power | Kw | 2.2 |
| Code | Items | Details | Remarks |
|---|---|---|---|
| 1 | Machine warranty | 12 months | - |
| 2 | Service response time | Within 24 hours | - |
| 3 | Installation and Commissioning Fees at End User Site |
• Within 10 days: included • Over 10 days: USD 200 per day and per person plus travel costs and accommodation • Translator cost will be paid by end user, additional travel costs, meals, accommodation |
- |
The vertical placement and middle connection promote metal wave circulation through the groove. This movement is highly beneficial for degassing, removing impurities, and maintaining a uniform chemical composition in the melt.
The furnace features built-in redundancy: if either of the two induction loops stops working, heating can be maintained by the remaining loop to re-melt the material and seamlessly resume operations.
Based on the target hourly copper output, the electric furnace automatically selects the most suitable of its 6 power string gears for heating or heat preservation using PID control. This accurately regulates copper water temperature while saving electrical energy.
The machine comes with a 12-month standard warranty. In case of operational or technical issues, the service response time is guaranteed within 24 hours.
Our standard payment terms require a 50% TT deposit after the contract is signed, with the remaining 50% TT payment due prior to delivery. The standard delivery timeframe is 90 days after contract confirmation.
The coil is cooled dynamically using a high-efficiency exhaust system that maintains optimal temperature thresholds during high-capacity operations.
