Industrial sand core shooting machine for metal casting production
Outstanding quality sand core shooting machine designed specifically for the casting industry in metal casting production, ensuring precision and reliability.
| Code | Items | Parameters |
|---|---|---|
| 1 | Robot Cell (FANUC) | M20iD/35 |
| 2 | Sand Belt Machine | 1421*1625*2385mm |
| 3 | Cloth wheel polishing machine | 1000**1500*2200mm |
| 4 | Double-layers feeding table | Double-layers feeding table |
| 5 | Fixture | 400 mm |
| 6 | Max. Power of sand belt machine | 16 KW |
| 7 | Max. Power of polishing machine | 17.5 KW |
| 8 | Machine base | Standard |
| 9 | Voltage | 380V |
| 10 | Sand Belt specification | 4000MM/2500MM |
| 11 | Max. Liner speed of grinding | 29M/S |
| 12 | Max. Liner speed of polishing | 45M/S |
| 13 | Three-phase induction motor | 3KW-4P (1440r/min) |
| 14 | Air Pressure | 0.4~0.7Mpa |
| 15 | Machine size | 2400*3800*2700mm |
| 16 | Total Weight | 4000KG |
| 17 | Air cylinder | AirTAC |
| 18 | Bearing | NSK |
| 19 | Open guide slide block | LSPB |
| 20 | Open linear guide | LSPB |
| 21 | Three-phase induction motor | Planet |
| 22 | HMI | Delta |
| 23 | PLC | Delta |
| 24 | Cloth wheels dimension | Dia. 600 (Customizable width) |
| Code | Items | Details | Remarks |
|---|---|---|---|
| 1 | Machine warranty | 12 months | - |
| 2 | Service response time | Within 24 hours | - |
| 3 | Installation & Commissioning | Included within 10 days | USD 200/day per person after 10 days |
A global leader in intelligent manufacturing solutions, specializing in low-pressure die casting, grinding, polishing, and automation systems. Offerings include automatic LPDC machines, robotic cell systems, CNC polishing equipment, and turnkey production lines.
With exports to over 30 countries—including the USA, Mexico, India, and Southeast Asia—and partnerships with premium global brands, we drive innovation through proprietary technologies like dynamic pressure control and multi-axis robotic algorithms.
Equipped with 50+ patents and a robust R&D team, the company delivers end-to-end solutions from mold design to lean factory layouts, backed by CE certification and a commitment to liberating labor through intelligent automation.
1. What is the standard warranty period for the machinery?
The machine comes with a comprehensive 12-month warranty from the date of installation.
2. How quickly can I expect a response for technical service?
We guarantee a service response within 24 hours to ensure minimal downtime for your production line.
3. What is the typical delivery timeframe after order confirmation?
The standard delivery time is 90 days once the contract is signed and confirmed.
4. Is on-site installation and commissioning available?
Yes, we provide installation and commissioning. Costs for the first 10 days are typically included in the service package.
5. Can the cloth wheel dimensions be customized for specific polishing needs?
Yes, while the standard diameter is 600mm, the width of the cloth wheels can be customized to fit your specific production requirements.
6. What power supply is required for these industrial machines?
The machines operate on a standard industrial voltage of 380V.
