Industrial sand core shooting machine for high-efficiency metal casting production. This equipment offers outstanding quality for the casting industry, specifically designed for metal casting production lines.
| Code | Items | Parameters |
|---|---|---|
| 1 | Robot Cell (FANUC) | M20iD/35 |
| 2 | Sand Belt Machine | 1421*1625*2385mm |
| 3 | Cloth wheel polishing machine | 1000*1500*2200mm |
| 4 | Double-layers feeding table | Customized available |
| 5 | Fixture | 400 mm |
| 6 | Max. Power (Sand Belt) | 16 KW |
| 7 | Max. Power (Cloth Wheel) | 17.5 KW |
| 9 | Voltage | 380V |
| 10 | Sand Belt specification | 4000MM/2500MM |
| 11 | Max. Liner speed (Grinding) | 29M/S |
| 12 | Max. Liner speed (Polishing) | 45M/S |
| 13 | Three-phase induction motor | 3KW-4P (1440r/min) |
| 14 | Air Pressure | 0.4~0.7Mpa |
| 15 | Machine size | 2400*3800*2700mm |
| 16 | Total Weight | 4000KG |
| 17 | Air cylinder | AirTAC |
| 18 | Bearing | NSK |
| 22 | HMI | Delta |
| 23 | PLC | Delta |
| 24 | Cloth wheels dimension | Dia. 600 (Width customized) |
| Code | Items | Details |
|---|---|---|
| 1 | Machine warranty | 12 months |
| 2 | Service response time | Within 24 hours |
| 3 | Installation | Included within 10 days; specific terms apply for extended periods. |
Notes:
We are a global leader in intelligent manufacturing solutions specializing in low-pressure die casting, grinding, polishing, and automation systems. Our core offerings include automatic LPDC machines, robotic cell grinding/polishing systems, CNC polishing equipment, and turnkey production lines.
With exports to over 30 countries and partnerships with global top-tier brands, we empower manufacturers with safer, greener, and smarter production through proprietary technologies like dynamic pressure control and multi-axis robotic algorithms.
Our dedicated R&D team drives innovation with over 50 patents. We deliver end-to-end solutions—from mold design to lean factory layouts—backed by global support and localized service centers.
